Features

• Interfaces directly with Ampex 300, 350 & 351 tape transports.

• Accommodates a wide variety of original equipment and replacement heads.

• Solid state monitor and equalization switching eliminates contact noise and permits remote control of both these functions.

• Fully regulated internal power supply assures stable operation despite wide variations in line voltage.

• Plug-in circuit cards combine advantages of both IC and discrete circuitry for unexcelled performance and trouble-free operation.

Specifications

Frequency Response (in Hz)

• 15ips ±2dB / 30-15k

• 7.5ips ±2dB / 30-12k

• 3.75ips ±3dB / 30-8k

Signal-to-Noise Ratio (in dB)

• 15ips/OVERALL (u’wtd -66/ wtd -72)STANDBY (u’wtd -76/ wtd -83)
• 7.5ips/OVERALL (u’wtd -69/ wtd -74)STANDBY (u’wtd -76/wtd -83)
• 3.75ips/OVERALL (u’wtd -65/ wtd -72)STANDBY (u’wtd -72/wtd -79)

  Equalization

3-3/4 - 7-1/2 or 7-1/2 - NAB equalization with solid-state switching.

Erase/Bias Frequency

100kHz

Erasure

70dB erasure of 500Hz signal recorded 3dB below tape saturation.

Amplifier Distortion

• Record: <.1% THD at Operating Level/ <.2% THO 25dB above Operating Level

• Reproduce: <.1 % THD at Operating Level

Input

• Sensitivity: -20 to +8dBm

• Impedance: 10K, unbalanced (transformer optional)

Outputs

• Line Output -feeds 600 ohm line or bridging input at +4 or +8dBm.
• Front Panel headphone jack

Panel Controls

• RECORD GAIN (with preset CAL position)

• REPRO GAIN (with preset CAL position)

• MONITOR: Selects INPUT OR TAPE monitor, or activates REMOTE control of monitor functions.
• EQUALIZATION: Selects between PWR.OFF and LOW SPEED, HIGH SPEED or REMOTE equalization

Power Requirement

105 - 130 VAC, 50/60Hz, .3A (plus transport)

Size and Weight

3-1/2” x 19” x 9”; 171bs.
