Features

• Monitor your DAB and DAB+ signal from any remote location via the Internet

• Monitor both off-air DAB+ radio and Aux audio levels simultaneously with meters.

• StationRotation™ - monitor all station presets by ‘round robin’ sequencing, each with its specific alarm parameters. Select which presets to include in StationRotation.

• Enhanced audio streaming capabilities allowing up to 10 simultaneous remote listeners.

• Streaming is HE-AACv2 for improved audio quality and UDP streaming is supported for skimmers and recording.

• BandScanner™ gives a spectrum plot of all or part of Band III

• Sends instant error messages via email or SMS text; logs signal loss, audio loss, DAB/DAB+ loss

• Easy setup and operation; full SNMP support

• Headphone jack

• Password protection with two access levels. // Remote firmware updates. // User Manual is available on the Web interface.

Specifications

Tuning Range

DAB Band III, Mode I (174.928MHz- 239.200MHz); all EBU-specified frequency allocations (Blocks 5-12, A-D) plus Block 13 A-F

Receiver Sensitivity

10μV for error-free reception

Antenna Input

75-ohm (BNC)

Audio Codecs

MPEG-1 Audio Layer 2 (MP2); HE-AAC (AAC+)

Audio Response

±0.25dB, 20Hz-20kHz

AUX Program Line Input

AES3 (XLR) digital AUX input accepts 32kHz, 44.1kHz, 48kHz sampling with programmable input sensitivity.

Network Connection

RJ45 jack accepts universal TCP/IP connector to LAN/router/Internet.

Headphone Jack

3.5mm TRS with menu-adjustable level

Signal Parameters & Metadata Displayed

Frequency, RSSI, SNR, FIC Quality (FQ), CNR, FFT Offset, CNR FIB Error, CU Level, Ensemble Label & ID, Total Services, Total Components, Total CU, Time, Dynamic Label Segment & Size, Sample & Bit Rates, Gain, Mode & ServiceMode, Protection Info, Current CU & Address, Frequency & Block, Service Label & ID, PTY, Component Label & ID, Global ID, Country, Language, Character Set ID, L/R Audio Levels

Alarms

Audio Loss, Low Signal, DAB Loss; adjustable thresholds and delays

Alarm Logs

Alarms are logged and may be downloaded as daily, weekly or monthly CSV files.

Power Requirement

+12VDC at 110mA (2.1mm x 5.5mm coaxial); a universal inline switchmode power supply is provided.

Mounting Options

An optional rack adapter accepts up to three INOmini modules in a 1U rack space.

Size and Weight

• 1.6”H x 5.5”W x 5.5”D
• 4 lbs shipping weight

Environmental

Continuous operation at ambient temperatures between 32ºF/0ºC and 122ºF/50ºC; 0-95% relative humidity, non-condensing, altitudes to 10,000ft/3,048m.
